Marine Grade 5754 Aluminum Sheet High Strength 5754 Aluminum Plate

Marine Grade 5754 Aluminum Sheet High Strength 5754 Aluminum Plate
Marine Grade 5754 Aluminum Sheet High Strength 5754 Aluminum Plate Marine Grade 5754 Aluminum Sheet High Strength 5754 Aluminum Plate Marine Grade 5754 Aluminum Sheet High Strength 5754 Aluminum Plate Marine Grade 5754 Aluminum Sheet High Strength 5754 Aluminum Plate

Large Image :  Marine Grade 5754 Aluminum Sheet High Strength 5754 Aluminum Plate

Product Details:

Place of Origin: China or Imported
Brand Name: Domestic or Imported materials
Certification: Mill Certificate, SGS, ASTM
Model Number: A5754

Payment & Shipping Terms:

Minimum Order Quantity: 100kgs or Custom
Price: Negotiable
Packaging Details: Export Standard Wooden Pallet or Case
Delivery Time: Within 7 days or According to Order
Payment Terms: TT
Supply Ability: 30 Tons/Month
Detailed Product Description
Product Name: Marine Grade 5754 Aluminum Sheet High Strength 5754 Aluminum Plate Temper: O, H32
Grade: 5754 Alloy Or Not: Alloy
Type: Plate/ Sheet Application: Automobile
Standard: GB/T 3880-2012 Package: Wooden Pallet
High Light:

marine grade aluminium sheet

,

5754 aluminum sheet

Marine Grade 5754 Aluminum Sheet High Strength 5754 Aluminum Plate



Alloy 5754 aluminum plate sheet has excellent corrosion resistance especially to seawater and industrially polluted atmospheres. It has higher strength than 5251. This high strength makes 5754 highly suited to marine applications requiring a combination of strength and resistance to corrosion in sea water.



Alloy 5754 aluminum plate sheet is sold basic materials but with high ductility and elongation, also have very good corrosion resistance, very small tension of the basic materials. When making tooling, alloy 5754 aluminum plate sheet has consistent stability in the core of thick plates, have good welding properties as well.





Aluminum 5754 is used in:

  • Treadplate

  • Shipbuilding

  • Vehicle bodies

  • Rivets

  • Fishing industry equipment

  • Food processing

  • Welded chemical and nuclear structures



Chemical Composition WT(%)
Silicon Iron Copper Magnesium Manganese Chromium Zinc Titanium Others Aluminum
0.4 0.4 0.1 2.6~3.6 0.5 0.3 0.2 0.15 0.15 Balance

Typical Mechanical Properties

Thickness

(mm)

Tensile Strength

(Mpa)

Yield Strength

(Mpa)

Elongation

(%)

0.3~350 265~305 ≥190 ≥2







Application


Ship-Building

Marine Grade 5754 Aluminum Sheet High Strength 5754 Aluminum Plate 0





FAQ

1. Are you a manufacturer or trading company ?
We are Shanghai trading company with procesing machines and stocks, can provide customize size and processing servies.
2. When can I get your reply after the inquiry.
Within 15 minutes during working time, whthin 12 hours during non-working time.
3. How can I get an accurate quote?
Please provide the information of prodcuts standard, material, size and quantity.
4. What is your MOQ?
There is no MOQ with stock size, and others is 100 KG.
5. How long is your delivery time?
Within 5 days for stock size, 15-30 days for customized size.
6. Can you provide smples?
Yes, smples can be offered with only delivery fee.
